型号 Model No |
焦距 EFL |
通光孔径 F/NO |
最大像面尺寸 Image Size(Dia) |
视场角 Field of View Angle |
视野范围 | TV畸变 |
最近距离 MOD |
相对照度 Relative illumination |
接口 Mount |
|
| 1/1.8" | 1/3" | FOV | Distortion(TV) | |||||||
| DJ-FS0305A | 3.37mm | 2.8 | 1/2" | 86°×70° | 70°×50° | 400x300 | <1% | 0.1m | 78% | M12xP0.5 |
| DJ-FS0605A | 6mm | 2.8 | 1/1.8" | 60.6°×46.6° | 42.4°x32.4° | 243.2x182.4 | <0.5% | 0.1m | 60% | M12xP0.5 |
| DJ-FS0805A | 8mm | 2.8 | 1/1.8" | 47°×35.6° | 32.3°×24.6° | 178.9x134.2 | <0.3% | 0.12m | 60% | M12xP0.5 |
| DJ-FS1205A | 12mm | 2.8 | 1/1.8" | 32.8°×24.5° | 22.2°x16.7° | 120.3x90.2 | <0.2% | 0.1m | 68% | M12xP0.5 |
| DJ-FS1605A | 16mm | 2.8 | 1/1.8" | 24.4°×18.4° | 17.1°×12.3° | 84.2x63.2 | <0.1% | 0.1m | 80% | M12xP0.5 |
| DJ-FS2505A | 25mm | 2.8 | 1/1.8" | 15.6°×11.5° | 10.5°×7.8° | 51.6x38.7 | <0.05% | 0.2m | 75% | M12xP0.5 |
